A120 rails puas siv tau rau gantry cranes hauv cov chaw nres nkoj ntug hiav txwv?
Yog lawm,A120 crane rail(DIN 536 tus qauv) yog qhov tsim nyog thiab feem ntau siv rau gantry cranes thiab nkoj - mus rau -shore (STS) thawv cranes hauv cov chaw nres nkoj ntug hiav txwv.Lawv tau tsim tshwj xeeb rau cov ntawv siv hnyav- lub luag haujlwm uas cov log tsheb loj thiab tsis tu ncua, siab - yuav tsum tau ua haujlwm ntau zaus, ua rau lawv xaiv tus qauv rau qhov chaw nres nkoj thiab chaw nres nkoj.
Cov laj thawj tseem ceeb A120 Rails Suit Coastal Ports
- Siab Load Capacity:A120 rails muaj qhov hnyav ntawm nominal100 kg / m, tsim los txhawb nqa loj thawv cranes, suav nrog Roj Hmab Tired Gantry (RTG) thiab Rail Mounted Gantry (RMG) cranes.
- Robust Geometry:Qhov dav -base profile (220 mm luj,120 mm taub hau) muab kev ruaj ntseg zoo tshaj plaws rau sab nraud thiab faib cov khoom hnyav kom zoo rau cov qauv kev txhawb nqa.
A120 Rail Specifications:
| Loj | Lub taub hau (mm) | Qhov siab (mm) | Puag (mm) | Web (mm) | Nominal hnyav (kg / m) | Khoom siv | Ntev (m) |
|---|---|---|---|---|---|---|---|
| A120 | 120 | 105 | 220 | 75 | 100 | 700/900A/1100 | 10-12 |
- Hnav Resistance:Feem ntau tsim los ntawm siab- zog, qis- alloy steels nyiamua 71mn, cov ntsia hlau no tiv taus hnav thiab qaug zog los ntawm kev ua haujlwm tas mus li.
- Kev Tswj Corrosion:Thaum tsim nyog, siv nyob rau hauv ib puag ncig ntug hiav txwv feem ntau xav tau kev tiv thaiv tshwj xeeb los tiv thaiv ntsev - huab cua corrosion. Qhov no suav nrog kev siv cov txheej tiv thaiv, tiv thaiv- kev kho corrosion, lossis tshwj xeeb, siab -qib steel kom ntseeg tau ntev - lub sij hawm durability.
Rau ib puag ncig corrosive heev, Peb pom zoo kom tshwj xeeb los tiv thaiv - corrosion txheej los yog stainless hlau Cheebtsam rau fasteners los xyuas kom meej lub cev tiv taus huab cua hnyav marine.
Dab tsi yog qhov siab tshaj plaws qag load uas DIN536 A120 Rail tuaj yeem tiv taus?
DIN 536 A120 crane rail yog tsim los rau hnyav-lub luag haujlwm, siab- ntau zaus kev siv tshuab, feem ntau ua kom cov khoom nqa nqa nrog lub peev xwm ntawmTsawg dua lossis sib npaug li 320 tonnesnyob rau hauv cov txheej txheem kev khiav hauj lwm (piv txwv li, pob zeb hauv paus zog Ntau dua los yog sib npaug rau C30).
Thaum lub siab tshaj plaws qag yog txiav txim siab los ntawm cov kev tsheb ciav hlau tshwj xeeb - lub log, kev khiav hauj lwm ceev, thiab nres zaus, A120 rails feem ntau txhawb nqa siab heev hauv cov chaw nres nkoj thiab cov nroj tsuag steel. Qhov dav 120 hli lub taub hau thiab tuab lub web (72 hli) tso cai rau A120 kev tsheb nqaj hlau los tiv thaiv lub log siab, ua kom haum rau cov chaw tsim khoom loj {6}.
Dab tsi cuam tshuam rau lub load{0}}cov kabmob muaj peev xwm ntawm A120 Steel Rail?
Lub load-cov kabmob muaj peev xwm ntawm A120 steel rail- hnyav- lub luag haujlwm crane rail tsim raws li tus qauv DIN 536- feem ntau txiav txim siab los ntawm nwscov khoom muaj pes tsawg leeg, structural profile, thiab covkev ua haujlwm tshwj xeebntawm lub crane system.
| Qeb | Yam Tseem Ceeb | Kev cuam tshuam rau lub peev xwm |
| Khoom siv & qauv | U71Mn hlau; 120mm taub hau / 220mm puag; 72mm wb | Muab lub zog tensile siab thiab pom kev sib faib siab kom txo tau kev ntxhov siab. |
| Cov xwm txheej ua haujlwm | Log load / txoj kab uas hla; dynamic / cuam tshuam loads; sab zog | Loj diameters txhim kho lub peev xwm thauj khoom; dynamic thiab lateral rog txwv kev ua tau zoo. |
| Installation & Txhawb nqa | Tsis tu ncuasteel soleplates; welded clamps; lub hauv paus muaj zog | Uniform kev txhawb nqa thiab nrawm nrawm tiv thaiv kev ntxhov siab hauv zos thiab qaug zog. |
| Environment & Care | Corrosion; kub variations;niaj hnub tu | Kev tiv thaiv kev kho mob thiab lubrication tiv thaiv kev hnav- cuam tshuam txog kev ua tsis tiav thiab lub zog poob. |
FAQ
- Puas yog A120 rail tus qauv rau txhua qhov chaw nres nkoj gantry cranes?
Thaum A100 thiab A150 kuj tau siv, A120 rail profile yog feem ntau "nrab- hauv av" tus qauv rau niaj hnub STS thiab RMG cranes vim nws qhov zoo ntawm qhov hnyav thiab ruaj khov.
- Cov huab cua ntsev cuam tshuam li cas rau A120 rail qhov hnyav ib 'meter'?
A120 rail qhov hnyav ib 'meter' (101.2 kg) tsis hloov, tab sis nto oxidation tuaj yeem nyias qhov profile ntau xyoo lawm. Siv Qib 900A steel thiab kev tiv thaiv grout ntawm lub hauv paus pab tswj lub A120 rail qhov ntev ntev.
- Dab tsi ntawm clips yuav tsum tau siv rau ntug hiav txwv A120 crane lem?
Adjustable welded clips nrog kub -dip galvanized tiav yog qhov kev xaiv zoo tshaj. Lawv muab ib daim ntawv cog lus mus tas li rau lub hauv paus / Hlau Soleplates thaum tiv thaiv cov teebmeem corrosive ntawm ntug dej hiav txwv.
- Ntev npaum li cas A120 rail nyob rau hauv ib puag ncig chaw nres nkoj?
Nrog kev saib xyuas kom zoo ntawm A120 rail accessories thiab kev siv qib S900 lossis S1100 steel, qhov chaw nres nkoj -raws li DIN536 A120 Rail System feem ntau muaj kev pabcuam lub neej ntawm 15 txog 25 xyoo.
- Puas yog cov khoom siv roj hmab yuav tsum tau ua rau qhov chaw nres nkoj A120 nyiaj siv ua haujlwm crane rail systems?
Yog lawm. Rau A120 hnyav rails, lub ncoo yog ib qho tseem ceeb rau absorbing dynamic vibrations ntawm lub crane thiab tiv thaiv kev sib cuag ncaj qha ntawm txoj kev tsheb ciav hlau thiab lub soleplate, uas yuav ua rau kom ceev corrosion thiab qaug zog.
Tau txais cov lus hais hauv 24 teev
GNEE RAILtshwj xeeb hauv kev muab tag nrho DIN536 A120 Rail System tshwj xeeb rau kev ua dej hiav txwv thiab chaw nres nkoj. Los ntawm siab - tensile A120 steel rails mus rau corrosion -resistant A120 rail accessories, peb muab cov kev txawj ntse los xyuas kom meej koj cov ntug hiav txwv gantry lem muaj kev nyab xeeb thiab zoo.
